Key Features:
Specification:
Communication Type
Transceiver
Port Number
1
Transmission Signal
Video
Connector
BNC, Terminal Block
Impedance
BNC: 75O; Terminal Block: 100O
Wire Cable
Category 2 or better; Unshielded Twisted Pair 24-16 AWG (0.5-1.31mm)
Power Distance*1
Non
Video Distance*1
Please refer to Video Distance Chart
Surge Suppression
Yes. Vs=40V, VDRM=25V, Ipp=45Amp
RF Noise Immunity
Yes
Cross Talk Immunity
Distance Equalization
PTZ Control
Environmental
Temperature: 0 -50° Humidity: 0%-95% ( Non-condensing)
Power request
Dimension (WxHxL)
25x25x35 mm
Weight
25 mg
Download Manual
